Desorption Electrolysis System
Manufacturer: Xinhai
- Product Introduction : Desorption electrolysis system obtains gold mud from carbon by desorption and electrowinning
-
Gold Loaded Carbon Content : ≥3.5kg/t
- Product Improvement : Desorption electrolysis system consists of electrolysis equipment including desorption column and the electrodeposition tank
-
Advantages
In the high temperature (150℃) and pressure (0.5MPa), the desorption rate reaches 98%
Since desorption and electrolysis does not require different temperatures, it is not necessary to change temperature. The quickness and efficiency of machine dramatically diminishes gross electricity consumption by 1/2-1/4.
Desorption does not require sodium cyanide, which reduces cost and averts pollution.
-
3D Exploded Video
Every single part and working principles of Desorption Electrolysis System are showed in Xinhai 3D video, which is really convenient for you to see the structure and working principles of those large equipment. Product Video
Product Detial
| Model | Suitable Scale | System Equipment List | System Instrument List | Operation Parameters | |
| Mine Scale (t/d) | Raw Ore Grade (g/t) | ||||
| GJD-200 | < 150 | 2~8 |
$1 Desorption Column $2 Filter $3 Electrolytic Tank $4 Circulating Pump $5 Electric Heater $6 Carbon Ejector $7 Air Compressor $8 Desorption Solution Tank $9 Clarified Water Pump $10 Acid Storage Tank $11 Magnetic Pump $12 Carbon Storage Tank $15 Control Cabinet $16 Silicon Rectifier Cabinet $17 Pickling Tank |
B1 Electric Resistance Remote Transmission Diaphragm-Seal Pressure Gauge B1 Pressure Indication Adjusting Meter B2 Diaphragm Pressure Gauge B3 Vortex Shedding Flowmeter B3 Flow Integrating Instrument B4 Thermal Temperature Meter B5 Temperature Sensor B5 Temperature IndicationAdjusting Meter P6 Diaphragm Pressure Gauge B7 Level Meter B9 Temperature Sensor B9 Temperature Indication Adjusting Meter |
Desorption Solution: PH > 13.5 Infinite 100-110°C Electrolysis Ending: Electrolysis Current: 350-1250A Electrolysis Pressure: 2-4V 150C : 0.50-0.57MPa Electrolytic Tank: 0.45-0.52MPa |
| GJD-300 | 150~300 | ||||
| GJD-450 | |||||
| GJD-500 | 300~500 | ||||
| GJD-600 | |||||
| GJD-750 | |||||
| GJD-1000 | 500~1000 | ||||
| GJD-1200 | |||||
| GJD-1500 | |||||
| GJD-1800 | |||||
| GJD-2000 | 1000~2000 | ||||
| GJD-2500 | |||||
| GJD-3000 | |||||
| GJD-3500 | 2000~3000 | 2~20 | |||
| GJD-4000 | |||||
| GJD-5000 | |||||
| Especial | > 3000 | ||||
In gold electrowinning process,when the electrolysis equipment is added with anions which are more easily absorbed by activated carbons, Au（CN）2ˉ is replaced by anion and the gold desorption is achieved. After the carbons loaded with gold are desorbed, pregnant solution is process via ionization. At last, solid gold is attained.
The analytical column, electrolytic tank, filter, heater, analytical solution agitation tank, control electric wheel, DC power supply, measuring instrument
